Hochspannung Lithium-Polymer-Akku

3.7V Cell: 5C 10C 15C 20C 25C 30C 35C 40C 50C 60C

Entladestrom C Rating beschreibt, wie schnell eine Batterie entladen werden kann. Ein 3000mAh Lithium-Polymer-Akku mit C-Bewertung von 1C kontinuierliche würde bedeuten, es sollte nicht schneller als 3000mA entladen werden (3A), was eine Stunde dauern. Ein 2000mAh Pack für kontinuierliche Bewertung und 5C der Lage wäre, die Entlastung zu 5 mal seine Kapazität (5 x 3000mA = 15000mA oder 15A), bei der Rate wäre die Entlastung 1:5 von einer Stunde. Mit einer Packung mit einer höheren Bewertung C, als Sie noch Raum für Sicherheit zu verlassen, und verlängern die Lebensdauer Ihres Lithium Polymer Batterie benötigen.

Dauerstrom
Wenn Sie, wie viel Dauerstrom gezogen werden und die Kapazität der Packung die Sie verwenden möchten wissen, können Sie leicht ermitteln, welche C-Bewertung die Sie benötigen. Wenn Sie Zeichnung 5A sind aus einem 2000mAh Pack, nehmen Sie einfach die aktuelle und dividiert durch die Kapazität: 5A = 5000mA, 5000mA / 2000mAh = 2.5C.

Aktuelle Burst
Lithium-Polymer-Akku ist auch eine C-Bewertung im Hinblick auf die platzen, die, wie schnell die Batterie in der Lage, die Entlastung für eine kurze Zeit ist gegeben. Ein Burst-Rating von 10C würde eine 3000mAh Batterie liefern könnten 10 x 3000mA = 30000mA oder 30A für ein paar Sekunden.

So wählen Sie die besten Lithium-Polymer-Akku für Ihr RC Helikopter
So wählen Sie einen Akku für Ihr RC Hubschrauber, müssen Sie zuerst wissen, was Sie benötigen und Spannung, wie viel Strom Sie kontinuierlich Zeichnung. Wenn der Motor in Ihrem RC Hubschrauber ist so ausgelegt, mit 14,8 arbeiten, müssten Sie ein 4-Zellen-Akku. Wenn Sie zu 10A ziehen müssen, und Sie würden Ihren RC Hubschrauber 10 Minuten (1:6 eine Stunde = 6C) Flug haben wollen, würden Sie eine Batterie mit 10A / 6 = 1,7 A = 1700mAh müssen. Das heißt, Sie müssten ein 3s 1700mAh Akku mit einer C-Bewertung von 6 oder höher in Ihrem RC Hubschrauber setzen.

Hohe Energiedichte C rating Lithium-Polymer-Akku
Thickness 2.5mm to 2.8mm, 40mAh to 220mAh, 1C to 2C

Part Number	Length (mm)	Height (mm)	Thickness (mm)	C-rating	Capacity (mAh)	Voltage (V)	LPHD250830	30	8	2.5	1	40	3.7
LPHD252848	48	28	2.5	1	220	3.7
LPHD253048	48	30	2.5	1	220	3.7
LPHD280819	19	8	2.8	1	27	3.7



Hohe Energiedichte C rating Lithium-Polymer-Akku
Thickness 3.2mm to 3.9mm, 70mAh to 5660mAh, 1C to 30C

Part Number	Length (mm)	Height (mm)	Thickness (mm)	C-rating	Capacity (mAh)	Voltage (V)
LPHD321429	29	14	3.2	10	70	3.7
LPHD334969	69	49	3.3	1	1200	3.7
LPHD354883	83	48	3.5	5	1400	3.7
LPHD361745	45	17	3.6	15	150	3.7
LPHD3634101	101	34	3.6	30	1000	3.7
LPHD372438	38	24	3.7	1	380	3.7
LPHD372629	29	26	3.7	1	220	3.7
LPHD382438	38	24	3.8	1	410	3.7
LPHD3967182	182	67	3.9	1	5660	3.7
LPHD3994129	129	94	3.9	1	5600	3.7



Hohe Energiedichte C rating Lithium-Polymer-Akku
Thickness 4.0mm to 4.9mm, 80mAh to 4000mAh, 15C to 30C

Part Number	Length (mm)	Height (mm)	Thickness (mm)	C-rating	Capacity (mAh)	Voltage (V)
LPHD401935	35	19	4	15	160	3.7
LPHD401940	40	19	4	15	200	3.7
LPHD403048	48	30	4	20	300	3.7
LPHD403048	48	30	4	20	350	3.7
LPHD403048	48	30	4	30	450	3.7
LPHD403438	38	34	4	1	520	3.7
LPHD403496	96	34	4	15	1100	3.7
LPHD403496	96	34	4	20	1000	3.7
LPHD404385	85	43	4	10	1250	3.7
LPHD4144120	120	44	4.1	30	1800	3.7
LPHD421035	35	10	4.2	15	80	3.7
LPHD422030	30	20	4.2	5	160	3.7
LPHD422030	30	20	4.2	20	110	3.7
LPHD422030	30	20	4.2	10	150	3.7
LPHD423455	55	34	4.2	1	800	3.7
LPHD424360	60	43	4.2	1	1000	3.7
LPHD4344100	100	44	4.3	10	1600	3.7
LPHD443048	48	30	4.4	15	480	3.7
LPHD443048	48	30	4.4	20	450	3.7
LPHD443085	85	30	4.4	20	700	3.7
LPHD4434106	106	34	4.4	20	1300	3.7
LPHD444694	94	46	4.4	1	1500	3.7
LPHD445265	65	52	4.4	5	1500	3.7
LPHD446586	86	65	4.4	25	2200	3.7
LPHD451945	45	19	4.5	15	250	3.7
LPHD4520122	122	20	4.5	15	800	3.7
LPHD452530	30	25	4.5	20	200	3.7
LPHD452535	35	25	4.5	20	250	3.7
LPHD453048	48	30	4.5	20	430	3.7
LPHD453142	42	31	4.5	20	400	3.7
LPHD453450	50	34	4.5	1	750	3.7
LPHD453496	96	34	4.5	20	1300	3.7
LPHD462845	45	28	4.6	20	450	3.7
LPHD462845	45	28	4.6	30	450	3.7
LPHD4642126	126	42	4.6	20	2000	3.7
LPHD471950	50	19	4.7	15	300	3.7
LPHD471955	55	19	4.7	15	350	3.7
LPHD472530	30	25	4.7	15	230	3.7
LPHD473040	40	30	4.7	20	350	3.7
LPHD473048	48	30	4.7	25	450	3.7
LPHD473048	48	30	4.7	20	450	3.7
LPHD473976	76	39	4.7	5	1550	3.7
LPHD481530	30	15	4.8	20	120	3.7
LPHD4819160	160	19	4.8	15	1300	3.7
LPHD483030	30	30	4.8	5	300	3.7
LPHD483048	48	30	4.8	20	500	3.7
LPHD4834106	106	34	4.8	20	1450	3.7
LPHD483496	96	34	4.8	20	1200	3.7
LPHD483496	96	34	4.8	10	1450	3.7
LPHD483562	62	35	4.8	20	650	3.7
LPHD484360	60	43	4.8	20	1050	3.7
LPHD4849135	135	49	4.8	15	3200	3.7
LPHD493496	96	34	4.9	30	1400	3.7
LPHD4945160	160	45	4.9	5	4000	3.7



Hohe Energiedichte C rating Lithium-Polymer-Akku
Thickness 3.2mm to 3.9mm, 120mAh to 5700mAh, 15C to 35C

Part Number	Length (mm)	Height (mm)	Thickness (mm)	C-rating	Capacity (mAh)	Voltage (V)
LPHD501140	40	11	5	15	120	3.7
LPHD5016185	185	16	5	20	1300	3.7
LPHD501795	95	17	5	15	650	3.7
LPHD5019160	160	19	5	15	1300	3.7
LPHD501940	40	19	5	10	280	3.7
LPHD5020100	100	20	5	15	850	3.7
LPHD502035	35	20	5	20	230	3.7
LPHD503030	30	30	5	1	390	3.7
LPHD503030	30	30	5	10	300	3.7
LPHD503048	48	30	5	25	500	3.7
LPHD5034100	100	34	5	15	1500	3.7
LPHD503476	76	34	5	20	1000	3.7
LPHD503496	96	34	5	20	1050	3.7
LPHD503496	96	34	5	30	1200	3.7
LPHD503562	62	35	5	20	800	3.7
LPHD503562	62	35	5	10	1000	3.7
LPHD5042126	126	42	5	30	2400	3.7
LPHD504358	58	43	5	5	1400	3.7
LPHD5045150	150	45	5	25	2650	3.7
LPHD504964	64	49	5	1	1800	3.7
LPHD505180	80	51	5	1	2200	3.7
LPHD5080125	125	80	5	8	5250	3.7
LPHD513048	48	30	5.1	25	600	3.7
LPHD513562	62	35	5.1	1	1200	3.7
LPHD5219160	160	19	5.2	25	1250	3.7
LPHD5234122	122	34	5.2	10	2100	3.7
LPHD523460	60	34	5.2	10	930	3.7
LPHD523496	96	34	5.2	15	1500	3.7
LPHD523562	62	35	5.2	15	1000	3.7
LPHD5242126	126	42	5.2	20	2600	3.7
LPHD524285	85	42	5.2	15	2000	3.7
LPHD524380	80	43	5.2	8	1800	3.7
LPHD524694	94	46	5.2	20	1500	3.7
LPHD524694	94	46	5.2	10	1600	3.7
LPHD524969	69	49	5.2	1	2000	3.7
LPHD5267100	100	67	5.2	5	4000	3.7
LPHD527096	96	70	5.2	5	4000	3.7
LPHD532030	30	20	5.3	15	210	3.7
LPHD533496	96	34	5.3	15	1500	3.7
LPHD533496	96	34	5.3	35	1400	3.7
LPHD533562	62	35	5.3	15	900	3.7
LPHD5342124	124	42	5.3	15	2700	3.7
LPHD5342124	124	42	5.3	20	2500	3.7
LPHD5342126	126	42	5.3	20	2400	3.7
LPHD5342126	126	42	5.3	30	2600	3.7
LPHD5343128	128	43	5.3	20	2400	3.7
LPHD5345135	135	45	5.3	20	3000	3.7
LPHD5346143	143	46	5.3	20	3300	3.7
LPHD543082	82	30	5.4	1	1500	3.7
LPHD543351	51	33	5.4	10	800	3.7
LPHD543496	96	34	5.4	20	1050	3.7
LPHD5442126	126	42	5.4	15	2900	3.7
LPHD544280	80	42	5.4	20	1600	3.7
LPHD5443128	128	43	5.4	20	2500	3.7
LPHD544473	73	44	5.4	1	2000	3.7
LPHD5446143	143	46	5.4	20	3200	3.7
LPHD544694	94	46	5.4	20	1600	3.7
LPHD544992	92	49	5.4	20	1650	3.7
LPHD5459156	156	59	5.4	5	5700	3.7
LPHD546474	74	64	5.4	25	1700	3.7
LPHD551130	30	11	5.5	15	110	3.7
LPHD551628	28	16	5.5	10	150	3.7
LPHD551675	75	16	5.5	20	530	3.7
LPHD551675	75	16	5.5	10	630	3.7
LPHD5517130	130	17	5.5	20	1080	3.7
LPHD551768	68	17	5.5	15	500	3.7
LPHD551795	95	17	5.5	20	780	3.7
LPHD5519160	160	19	5.5	15	1400	3.7
LPHD551996	96	19	5.5	15	850	3.7
LPHD551996	96	19	5.5	15	950	3.7
LPHD5520122	122	20	5.5	15	1080	3.7
LPHD5520122	122	20	5.5	30	950	3.7
LPHD5520122	122	20	5.5	30	1100	3.7
LPHD5520122	122	20	5.5	15	1200	3.7
LPHD552030	30	20	5.5	1	200	3.7
LPHD552030	30	20	5.5	20	180	3.7
LPHD5530100	100	30	5.5	25	1250	3.7
LPHD553048	48	30	5.5	15	600	3.7
LPHD553048	48	30	5.5	20	600	3.7
LPHD553085	85	30	5.5	15	1200	3.7
LPHD553085	85	30	5.5	20	1100	3.7
LPHD5534100	100	34	5.5	20	1750	3.7
LPHD553496	96	34	5.5	15	1500	3.7
LPHD553496	96	34	5.5	20	1400	3.7
LPHD553496	96	34	5.5	30	1650	3.7
LPHD553562	62	35	5.5	30	1000	3.7
LPHD5536110	110	36	5.5	1	2500	3.7
LPHD5542124	124	42	5.5	20	2800	3.7
LPHD5542126	126	42	5.5	15	2900	3.7
LPHD5542126	126	42	5.5	35	2700	3.7
LPHD5542126	126	42	5.5	5	3500	3.7
LPHD5542126	126	42	5.5	15	2850	3.7
LPHD5542126	126	42	5.5	20	2750	3.7
LPHD5543128	128	43	5.5	20	2500	3.7
LPHD5545150	150	45	5.5	20	3200	3.7
LPHD5551143	143	51	5.5	10	4200	3.7
LPHD555180	80	51	5.5	1	2500	3.7
LPHD5559156	156	59	5.5	5	5700	3.7
LPHD556094	94	60	5.5	1	3300	3.7
LPHD556479	79	64	5.5	15	2800	3.7
LPHD556586	86	65	5.5	5	3500	3.7
LPHD5620122	122	20	5.6	15	1100	3.7
LPHD562464	64	24	5.6	10	800	3.7
LPHD563048	48	30	5.6	15	630	3.7
LPHD563476	76	34	5.6	8	1650	3.7
LPHD563496	96	34	5.6	25	1650	3.7
LPHD563496	96	34	5.6	15	1700	3.7
LPHD563562	62	35	5.6	30	1000	3.7
LPHD5642126	126	42	5.6	25	2850	3.7
LPHD5642126	126	42	5.6	15	3000	3.7
LPHD5642126	126	42	5.6	40	2400	3.7
LPHD564280	80	42	5.6	15	1900	3.7
LPHD564280	80	42	5.6	8	2100	3.7
LPHD5645135	135	45	5.6	15	3300	3.7
LPHD5653105	105	53	5.6	30	2900	3.7
LPHD5665126	126	65	5.6	5	5200	3.7
LPHD571636	36	16	5.7	20	200	3.7
LPHD573496	96	34	5.7	20	1500	3.7
LPHD573562	62	35	5.7	15	1000	3.7
LPHD5742126	126	42	5.7	30	2500	3.7
LPHD574280	80	42	5.7	15	1950	3.7
LPHD574283	83	42	5.7	15	2150	3.7
LPHD574283	83	42	5.7	20	2050	3.7
LPHD574285	85	42	5.7	8	2500	3.7
LPHD574285	85	42	5.7	20	2000	3.7
LPHD574285	85	42	5.7	15	2150	3.7
LPHD574285	85	42	5.7	20	2050	3.7
LPHD574285	85	42	5.7	20	1950	3.7
LPHD574380	80	43	5.7	15	1930	3.7
LPHD574380	80	43	5.7	20	1800	3.7
LPHD574380	80	43	5.7	30	1600	3.7
LPHD5753105	105	53	5.7	20	2900	3.7
LPHD581130	30	11	5.8	15	120	3.7
LPHD581147	47	11	5.8	20	200	3.7
LPHD581640	40	16	5.8	15	240	3.7
LPHD581855	55	18	5.8	25	420	3.7
LPHD5820122	122	20	5.8	15	1100	3.7
LPHD583040	40	30	5.8	1	600	3.7
LPHD583048	48	30	5.8	15	770	3.7
LPHD583048	48	30	5.8	15	650	3.7
LPHD583048	48	30	5.8	20	620	3.7
LPHD583060	60	30	5.8	20	600	3.7
LPHD583496	96	34	5.8	25	1500	3.7
LPHD583562	62	35	5.8	20	1000	3.7
LPHD5836128	128	36	5.8	15	2800	3.7
LPHD5836128	128	36	5.8	20	2200	3.7
LPHD5842126	126	42	5.8	20	2200	3.7
LPHD5842126	126	42	5.8	20	2600	3.7
LPHD5842126	126	42	5.8	30	2800	3.7
LPHD5842126	126	42	5.8	25	2200	3.7
LPHD584280	80	42	5.8	5	2280	3.7
LPHD584285	85	42	5.8	20	2000	3.7
LPHD584285	85	42	5.8	8	2400	3.7
LPHD5843128	128	43	5.8	20	2700	3.7
LPHD5843128	128	43	5.8	30	2600	3.7
LPHD5844175	175	44	5.8	20	4000	3.7
LPHD584473	73	44	5.8	1	2000	3.7
LPHD5845135	135	45	5.8	20	3000	3.7
LPHD5845150	150	45	5.8	20	3400	3.7
LPHD5845150	150	45	5.8	25	3200	3.7
LPHD584973	73	49	5.8	15	2000	3.7
LPHD585180	80	51	5.8	1	2800	3.7
LPHD5865132	132	65	5.8	5	5250	3.7
LPHD5870135	135	70	5.8	1	5900	3.7
LPHD587260	60	72	5.8	20	2150	3.7
LPHD592976	76	29	5.9	8	1250	3.7
LPHD593048	48	30	5.9	15	650	3.7
LPHD593476	76	34	5.9	20	1400	3.7
LPHD593482	82	34	5.9	20	1500	3.7
LPHD593496	96	34	5.9	25	1800	3.7
LPHD593562	62	35	5.9	25	1100	3.7
LPHD5938115	115	38	5.9	30	2400	3.7
LPHD5945150	150	45	5.9	20	3500	3.7
LPHD5946143	143	46	5.9	20	3800	3.7
LPHD5946143	143	46	5.9	30	3800	3.7
LPHD596078	78	60	5.9	30	2500	3.7
LPHD5967105	105	67	5.9	1	3300	3.7



Hohe Energiedichte C rating Lithium-Polymer-Akku
Thickness 6.0mm to 6.9mm, 160mAh to 15500mAh, 1C to 30C

Part Number	Length (mm)	Height (mm)	Thickness (mm)	C-rating	Capacity (mAh)	Voltage (V)
LPHD601140	40	11	6.0	15	160	3.7
LPHD601640	40	16	6.0	15	280	3.7
LPHD601662	62	16	6.0	15	430	3.7
LPHD601795	95	17	6.0	20	750	3.7
LPHD601844	44	18	6.0	20	300	3.7
LPHD6020122	122	20	6.0	15	1350	3.7
LPHD6020122	122	20	6.0	20	1150	3.7
LPHD602030	30	20	6.0	1	300	3.7
LPHD602030	30	20	6.0	10	200	3.7
LPHD602442	42	24	6.0	15	500	3.7
LPHD602442	42	24	6.0	15	450	3.7
LPHD602464	64	24	6.0	10	850	3.7
LPHD602486	86	24	6.0	15	1080	3.7
LPHD603048	48	30	6.0	20	650	3.7
LPHD603060	60	30	6.0	20	850	3.7
LPHD603085	85	30	6.0	15	1300	3.7
LPHD603085	85	30	6.0	20	1250	3.7
LPHD603351	51	33	6.0	20	850	3.7
LPHD603482	82	34	6.0	10	1550	3.7
LPHD603496	96	34	6.0	20	1600	3.7
LPHD603496	96	34	6.0	15	1800	3.7
LPHD6036128	128	36	6.0	20	2200	3.7
LPHD6038110	110	38	6.0	30	2200	3.7
LPHD6042124	124	42	6.0	20	2800	3.7
LPHD6042126	126	42	6.0	10	3500	3.7
LPHD6043128	128	43	6.0	30	2500	3.7
LPHD6044175	175	44	6.0	20	4000	3.7
LPHD604694	94	46	6.0	20	1800	3.7
LPHD6053105	105	53	6.0	25	2900	3.7
LPHD605582	82	55	6.0	30	2500	3.7
LPHD605998	98	59	6.0	5	4000	3.7
LPHD606078	78	60	6.0	1	2400	3.7
LPHD606078	78	60	6.0	20	2550	3.7
LPHD606078	78	60	6.0	20	2500	3.7
LPHD606164	64	61	6.0	1	2500	3.7
LPHD6063135	135	63	6.0	1	5000	3.7
LPHD6072196	196	72	6.0	8	8900	3.7
LPHD6072200	200	72	6.0	10	9000	3.7
LPHD6088106	106	88	6.0	1	5000	3.7
LPHD612548	48	25	6.1	5	700	3.7
LPHD612548	48	25	6.1	5	700	3.7
LPHD6134118	118	34	6.1	10	2500	3.7
LPHD613460	60	34	6.1	5	1350	3.7
LPHD613460	60	34	6.1	15	1200	3.7
LPHD613496	96	34	6.1	30	1800	3.7
LPHD614050	50	40	6.1	20	1100	3.7
LPHD614050	50	40	6.1	20	1000	3.7
LPHD614050	50	40	6.1	10	1150	3.7
LPHD6142155	155	42	6.1	8	4400	3.7
LPHD616078	78	60	6.1	20	2500	3.7
LPHD6167100	100	67	6.1	5	4500	3.7
LPHD6175175	175	75	6.1	15	8000	3.7
LPHD621935	35	19	6.2	20	300	3.7
LPHD622233	33	22	6.2	20	280	3.7
LPHD622530	30	25	6.2	15	300	3.7
LPHD622845	45	28	6.2	25	650	3.7
LPHD623048	48	30	6.2	1	650	3.7
LPHD623048	48	30	6.2	15	700	3.7
LPHD623048	48	30	6.2	5	900	3.7
LPHD623060	60	30	6.2	20	850	3.7
LPHD623060	60	30	6.2	20	900	3.7
LPHD623370	70	33	6.2	20	1000	3.7
LPHD623460	60	34	6.2	5	1350	3.7
LPHD623482	82	34	6.2	20	1500	3.7
LPHD623496	96	34	6.2	30	1800	3.7
LPHD623562	62	35	6.2	35	1000	3.7
LPHD623562	62	35	6.2	30	1000	3.7
LPHD6236128	128	36	6.2	20	2400	3.7
LPHD623758	58	37	6.2	1	1500	3.7
LPHD6240150	150	40	6.2	1	4400	3.7
LPHD624172	72	41	6.2	1	1600	3.7
LPHD6242126	126	42	6.2	30	2700	3.7
LPHD624358	58	43	6.2	20	1000	3.7
LPHD624590	90	45	6.2	1	3000	3.7
LPHD6248150	150	48	6.2	20	4000	3.7
LPHD625094	94	50	6.2	1	3700	3.7
LPHD626078	78	60	6.2	20	2500	3.7
LPHD626474	74	64	6.2	20	2000	3.7
LPHD626496	96	64	6.2	20	2800	3.7
LPHD6265135	135	65	6.2	1	5500	3.7
LPHD6265135	135	65	6.2	20	4000	3.7
LPHD626590	90	65	6.2	1	4300	3.7
LPHD632660	60	26	6.3	20	750	3.7
LPHD632845	45	28	6.3	30	650	3.7
LPHD633048	48	30	6.3	15	650	3.7
LPHD633496	96	34	6.3	25	1800	3.7
LPHD633562	62	35	6.3	25	1000	3.7
LPHD633562	62	35	6.3	35	1000	3.7
LPHD633562	62	35	6.3	20	1000	3.7
LPHD6342126	126	42	6.3	20	3000	3.7
LPHD634285	85	42	6.3	8	2600	3.7
LPHD634358	58	43	6.3	5	1500	3.7
LPHD6365132	132	65	6.3	1	5000	3.7
LPHD6365132	132	65	6.3	1	5000	3.7
LPHD6410100	100	10	6.4	1	5500	3.7
LPHD641996	96	19	6.4	15	1100	3.7
LPHD642464	64	24	6.4	15	830	3.7
LPHD642464	64	24	6.4	15	900	3.7
LPHD642464	64	24	6.4	10	850	3.7
LPHD643060	60	30	6.4	25	1000	3.7
LPHD643060	60	30	6.4	25	850	3.7
LPHD643126	26	31	6.4	15	430	3.7
LPHD643476	76	34	6.4	20	1400	3.7
LPHD6438115	115	38	6.4	30	2700	3.7
LPHD6442126	126	42	6.4	20	3200	3.7
LPHD6442126	126	42	6.4	20	3100	3.7
LPHD6442126	126	42	6.4	30	2800	3.7
LPHD6442126	126	42	6.4	15	3300	3.7
LPHD644295	95	42	6.4	5	3000	3.7
LPHD6443128	128	43	6.4	20	3100	3.7
LPHD6445150	150	45	6.4	15	4500	3.7
LPHD6446143	143	46	6.4	20	3800	3.7
LPHD645652	52	56	6.4	5	1900	3.7
LPHD6465132	132	65	6.4	5	4000	3.7
LPHD6465132	132	65	6.4	20	4000	3.7
LPHD6498220	220	98	6.4	5	15500	3.7
LPHD651640	40	16	6.5	15	280	3.7
LPHD651723	23	17	6.5	15	150	3.7
LPHD651726	26	17	6.5	15	180	3.7
LPHD651775	75	17	6.5	10	800	3.7
LPHD652030	30	20	6.5	15	250	3.7
LPHD652030	30	20	6.5	15	270	3.7
LPHD652138	38	21	6.5	10	400	3.7
LPHD652892	92	28	6.5	20	1150	3.7
LPHD6530125	125	30	6.5	1	8000	3.7
LPHD653040	40	30	6.5	15	650	3.7
LPHD653048	48	30	6.5	10	800	3.7
LPHD653060	60	30	6.5	15	1000	3.7
LPHD6531122	122	31	6.5	5	3000	3.7
LPHD653496	96	34	6.5	8	2150	3.7
LPHD653562	62	35	6.5	30	1000	3.7
LPHD6536102	102	36	6.5	5	2750	3.7
LPHD6536102	102	36	6.5	5	2950	3.7
LPHD6542126	126	42	6.5	30	3200	3.7
LPHD6542150	150	42	6.5	8	4650	3.7
LPHD6543128	128	43	6.5	20	3200	3.7
LPHD6543128	128	43	6.5	1	4000	3.7
LPHD654380	80	43	6.5	1	1850	3.7
LPHD6544100	100	44	6.5	20	2700	3.7
LPHD6545150	150	45	6.5	20	4000	3.7
LPHD655446	46	54	6.5	5	1800	3.7
LPHD6565132	132	65	6.5	1	5500	3.7
LPHD6570135	135	70	6.5	20	6000	3.7
LPHD657068	68	70	6.5	20	2000	3.7
LPHD657092	92	70	6.5	20	2950	3.7
LPHD657096	96	70	6.5	1	5450	3.7
LPHD6572200	200	72	6.5	10	10000	3.7
LPHD6575106	106	75	6.5	20	4700	3.7
LPHD6578156	156	78	6.5	25	6000	3.7
LPHD6588106	106	88	6.5	1	7500	3.7
LPHD6592162	162	92	6.5	1	12000	3.7
LPHD661340	40	13	6.6	5	230	3.7
LPHD661654	54	16	6.6	25	450	3.7
LPHD662689	89	26	6.6	15	1500	3.7
LPHD663060	60	30	6.6	15	1000	3.7
LPHD663496	96	34	6.6	20	1800	3.7
LPHD663562	62	35	6.6	15	1250	3.7
LPHD6642126	126	42	6.6	25	3550	3.7
LPHD6642126	126	42	6.6	20	3200	3.7
LPHD6642126	126	42	6.6	20	3300	3.7
LPHD6642126	126	42	6.6	30	3300	3.7
LPHD6642126	126	42	6.6	30	3400	3.7
LPHD6642126	126	42	6.6	20	3500	3.7
LPHD6643128	128	43	6.6	35	3000	3.7
LPHD6643128	128	43	6.6	25	3000	3.7
LPHD6644100	100	44	6.6	20	2700	3.7
LPHD6645135	135	45	6.6	1	5000	3.7
LPHD6646143	143	46	6.6	25	4200	3.7
LPHD6649140	140	49	6.6	10	5000	3.7
LPHD6651143	143	51	6.6	35	4400	3.7
LPHD667092	92	70	6.6	1	5000	3.7
LPHD6678156	156	78	6.6	25	6000	3.7
LPHD672342	42	23	6.7	30	500	3.7
LPHD673388	88	33	6.7	15	1950	3.7
LPHD673388	88	33	6.7	15	1800	3.7
LPHD6734122	122	34	6.7	10	2800	3.7
LPHD673496	96	34	6.7	15	2100	3.7
LPHD6742126	126	42	6.7	20	3300	3.7
LPHD6743128	128	43	6.7	35	3000	3.7
LPHD674360	60	43	6.7	8	1700	3.7
LPHD6744115	115	44	6.7	20	3300	3.7
LPHD674752	52	47	6.7	15	1700	3.7
LPHD6750115	115	50	6.7	5	5000	3.7
LPHD675365	65	53	6.7	1	2900	3.7
LPHD6756104	104	56	6.7	5	5100	3.7
LPHD6759145	145	59	6.7	1	7500	3.7
LPHD676164	64	61	6.7	5	3000	3.7
LPHD6770135	135	70	6.7	20	6000	3.7
LPHD6775106	106	75	6.7	1	4500	3.7
LPHD6810100	100	10	6.8	1	8000	3.7
LPHD681955	55	19	6.8	15	550	3.7
LPHD682025	25	20	6.8	15	200	3.7
LPHD682030	30	20	6.8	15	280	3.7
LPHD6831122	122	31	6.8	5	3000	3.7
LPHD683476	76	34	6.8	20	1650	3.7
LPHD683496	96	34	6.8	20	1800	3.7
LPHD683496	96	34	6.8	10	1800	3.7
LPHD683496	96	34	6.8	30	1800	3.7
LPHD683496	96	34	6.8	25	1800	3.7
LPHD683562	62	35	6.8	1	1650	3.7
LPHD683562	62	35	6.8	8	1550	3.7
LPHD683562	62	35	6.8	20	1200	3.7
LPHD683562	62	35	6.8	20	1300	3.7
LPHD683562	62	35	6.8	15	1400	3.7
LPHD683658	58	36	6.8	15	1400	3.7
LPHD6842125	125	42	6.8	20	3000	3.7
LPHD6842126	126	42	6.8	20	3150	3.7
LPHD6843128	128	43	6.8	15	3800	3.7
LPHD684358	58	43	6.8	30	1000	3.7
LPHD6845135	135	45	6.8	8	4800	3.7
LPHD6845180	180	45	6.8	1	5800	3.7
LPHD6846143	143	46	6.8	20	4200	3.7
LPHD684764	64	47	6.8	1	2500	3.7
LPHD6849135	135	49	6.8	30	4400	3.7
LPHD6850115	115	50	6.8	25	2800	3.7
LPHD6851143	143	51	6.8	10	5450	3.7
LPHD686164	64	61	6.8	1	3100	3.7
LPHD692437	37	24	6.9	30	450	3.7
LPHD692845	45	28	6.9	25	730	3.7
LPHD692978	78	29	6.9	30	1200	3.7
LPHD693388	88	33	6.9	5	2200	3.7
LPHD693450	50	34	6.9	15	1000	3.7
LPHD693496	96	34	6.9	5	2600	3.7
LPHD693496	96	34	6.9	30	2100	3.7
LPHD693562	62	35	6.9	15	1250	3.7
LPHD693562	62	35	6.9	25	1300	3.7
LPHD693562	62	35	6.9	15	1250	3.7
LPHD693658	58	36	6.9	15	1400	3.7
LPHD6938110	110	38	6.9	20	2750	3.7
LPHD6942126	126	42	6.9	5	4500	3.7
LPHD6943143	143	43	6.9	20	4200	3.7
LPHD694358	58	43	6.9	20	1500	3.7
LPHD6945135	135	45	6.9	8	4800	3.7
LPHD6945150	150	45	6.9	20	4000	3.7
LPHD6945150	150	45	6.9	30	4600	3.7
LPHD6945180	180	45	6.9	20	5500	3.7
LPHD6949135	135	49	6.9	1	6050	3.7
LPHD6949135	135	49	6.9	20	4500	3.7
LPHD695490	90	54	6.9	1	4000	3.7
LPHD695572	72	55	6.9	5	3200	3.7
LPHD696195	95	61	6.9	1	5000	3.7
LPHD6965132	132	65	6.9	25	4300	3.7
LPHD696586	86	65	6.9	25	3700	3.7



Hohe Energiedichte C rating Lithium-Polymer-Akku
Thickness 7.0mm to 7.9mm, 350mAh to 22000mAh, 15C to 40C

-

Part Number	Length (mm)	Height (mm)	Thickness (mm)	C-rating	Capacity (mAh)	Voltage (V)
LPHD701855	55	18	7.0	15	600	3.7
LPHD701988	88	19	7.0	15	1050	3.7
LPHD701996	96	19	7.0	15	1100	3.7
LPHD702035	35	20	7.0	15	350	3.7
LPHD702530	30	25	7.0	5	400	3.7
LPHD702689	89	26	7.0	15	1450	3.7
LPHD7030100	100	30	7.0	20	1750	3.7
LPHD703040	40	30	7.0	20	700	3.7
LPHD703048	48	30	7.0	15	800	3.7
LPHD703048	48	30	7.0	20	800	3.7
LPHD703060	60	30	7.0	20	1000	3.7
LPHD703082	82	30	7.0	10	1650	3.7
LPHD703142	42	31	7.0	20	500	3.7
LPHD703351	51	33	7.0	10	1100	3.7
LPHD7034106	106	34	7.0	20	2200	3.7
LPHD7034106	106	34	7.0	30	2200	3.7
LPHD703482	82	34	7.0	20	1800	3.7
LPHD703482	82	34	7.0	30	1800	3.7
LPHD703496	96	34	7.0	35	2000	3.7
LPHD703496	96	34	7.0	35	1800	3.7
LPHD703496	96	34	7.0	5	2600	3.7
LPHD703496	96	34	7.0	30	2100	3.7
LPHD703562	62	35	7.0	25	1200	3.7
LPHD703562	62	35	7.0	15	1300	3.7
LPHD703562	62	35	7.0	20	1200	3.7
LPHD703562	62	35	7.0	30	1250	3.7
LPHD703562	62	35	7.0	30	1300	3.7
LPHD703562	62	35	7.0	8	1550	3.7
LPHD703768	68	37	7.0	20	1500	3.7
LPHD7038110	110	38	7.0	20	2500	3.7
LPHD704172	72	41	7.0	5	2350	3.7
LPHD7042126	126	42	7.0	30	3100	3.7
LPHD7042126	126	42	7.0	15	3900	3.7
LPHD7042126	126	42	7.0	20	3700	3.7
LPHD7042126	126	42	7.0	15	3700	3.7
LPHD7043128	128	43	7.0	20	3200	3.7
LPHD704360	60	43	7.0	20	1500	3.7
LPHD704590	90	45	7.0	1	3600	3.7
LPHD7046143	143	46	7.0	20	4500	3.7
LPHD7049135	135	49	7.0	1	5000	3.7
LPHD7049135	135	49	7.0	35	4000	3.7
LPHD705582	82	55	7.0	1	2850	3.7
LPHD7058150	150	58	7.0	5	7000	3.7
LPHD7063124	124	63	7.0	1	5000	3.7
LPHD7067220	220	67	7.0	1	10000	3.7
LPHD7070135	135	70	7.0	20	5000	3.7
LPHD7070170	170	70	7.0	1	11000	3.7
LPHD708273	73	82	7.0	10	4100	3.7
LPHD708278	78	82	7.0	5	5100	3.7
LPHD708278	78	82	7.0	5	5000	3.7
LPHD7088106	106	88	7.0	1	7500	3.7
LPHD713048	48	30	7.1	20	850	3.7
LPHD713085	85	30	7.1	30	1600	3.7
LPHD713351	51	33	7.1	1	1250	3.7
LPHD713482	82	34	7.1	30	1800	3.7
LPHD713496	96	34	7.1	5	2600	3.7
LPHD713496	96	34	7.1	35	1800	3.7
LPHD713498	98	34	7.1	5	2800	3.7
LPHD713498	98	34	7.1	5	3050	3.7
LPHD713562	62	35	7.1	30	1300	3.7
LPHD713562	62	35	7.1	35	1300	3.7
LPHD7138115	115	38	7.1	20	2700	3.7
LPHD7142126	126	42	7.1	20	3800	3.7
LPHD7143128	128	43	7.1	20	4000	3.7
LPHD714358	58	43	7.1	20	1650	3.7
LPHD7145135	135	45	7.1	5	5400	3.7
LPHD714590	90	45	7.1	5	3600	3.7
LPHD7156104	104	56	7.1	5	5100	3.7
LPHD7170135	135	70	7.1	20	6000	3.7
LPHD7172200	200	72	7.1	10	11000	3.7
LPHD721662	62	16	7.2	15	600	3.7
LPHD721723	23	17	7.2	15	180	3.7
LPHD722035	35	20	7.2	20	350	3.7
LPHD722848	48	28	7.2	15	850	3.7
LPHD723040	40	30	7.2	20	650	3.7
LPHD723048	48	30	7.2	35	800	3.7
LPHD723048	48	30	7.2	30	850	3.7
LPHD723082	82	30	7.2	15	1600	3.7
LPHD723082	82	30	7.2	5	2050	3.7
LPHD7234106	106	34	7.2	5	2950	3.7
LPHD7234122	122	34	7.2	20	2200	3.7
LPHD723460	60	34	7.2	15	1400	3.7
LPHD723496	96	34	7.2	30	2200	3.7
LPHD723496	96	34	7.2	30	1800	3.7
LPHD723562	62	35	7.2	20	1300	3.7
LPHD7236128	128	36	7.2	20	3000	3.7
LPHD7242126	126	42	7.2	30	3500	3.7
LPHD7242126	126	42	7.2	30	3700	3.7
LPHD7243128	128	43	7.2	20	3400	3.7
LPHD724358	58	43	7.2	20	1500	3.7
LPHD724358	58	43	7.2	20	1600	3.7
LPHD724358	58	43	7.2	10	2000	3.7
LPHD724358	58	43	7.2	15	1850	3.7
LPHD7244115	115	44	7.2	5	4600	3.7
LPHD7245180	180	45	7.2	25	5600	3.7
LPHD7246143	143	46	7.2	25	4200	3.7
LPHD7249135	135	49	7.2	1	6300	3.7
LPHD7249135	135	49	7.2	1	6000	3.7
LPHD7250115	115	50	7.2	1	5000	3.7
LPHD7255145	145	55	7.2	1	5000	3.7
LPHD7259156	156	59	7.2	1	5400	3.7
LPHD7270156	156	70	7.2	5	9000	3.7
LPHD732437	37	24	7.3	15	520	3.7
LPHD732464	64	24	7.3	20	1000	3.7
LPHD733048	48	30	7.3	20	800	3.7
LPHD7334122	122	34	7.3	15	3000	3.7
LPHD733450	50	34	7.3	15	1000	3.7
LPHD733496	96	34	7.3	5	2950	3.7
LPHD733496	96	34	7.3	20	2200	3.7
LPHD733496	96	34	7.3	5	2600	3.7
LPHD733562	62	35	7.3	35	1300	3.7
LPHD733562	62	35	7.3	10	1450	3.7
LPHD7336128	128	36	7.3	15	3700	3.7
LPHD7342126	126	42	7.3	15	4100	3.7
LPHD7342126	126	42	7.3	35	3300	3.7
LPHD734358	58	43	7.3	10	1800	3.7
LPHD7344115	115	44	7.3	30	3200	3.7
LPHD7345135	135	45	7.3	5	5400	3.7
LPHD7345135	135	45	7.3	5	5800	3.7
LPHD7345150	150	45	7.3	20	4500	3.7
LPHD7349135	135	49	7.3	30	4400	3.7
LPHD7349135	135	49	7.3	20	4400	3.7
LPHD7351175	175	51	7.3	5	8000	3.7
LPHD7356104	104	56	7.3	5	5200	3.7
LPHD7365132	132	65	7.3	1	5000	3.7
LPHD7385155	155	85	7.3	15	10000	3.7
LPHD741730	30	17	7.4	20	260	3.7
LPHD741955	55	19	7.4	20	630	3.7
LPHD742437	37	24	7.4	10	550	3.7
LPHD742437	37	24	7.4	15	520	3.7
LPHD743048	48	30	7.4	20	650	3.7
LPHD743060	60	30	7.4	15	1200	3.7
LPHD743085	85	30	7.4	20	1600	3.7
LPHD743085	85	30	7.4	30	1600	3.7
LPHD743085	85	30	7.4	5	2000	3.7
LPHD743496	96	34	7.4	20	2100	3.7
LPHD743496	96	34	7.4	10	1800	3.7
LPHD743496	96	34	7.4	30	2300	3.7
LPHD743496	96	34	7.4	25	2200	3.7
LPHD743562	62	35	7.4	10	1100	3.7
LPHD7436128	128	36	7.4	20	3000	3.7
LPHD7439100	100	39	7.4	8	3100	3.7
LPHD7442126	126	42	7.4	20	3650	3.7
LPHD7443128	128	43	7.4	20	3600	3.7
LPHD7445135	135	45	7.4	25	4500	3.7
LPHD7445135	135	45	7.4	25	3000	3.7
LPHD7445180	180	45	7.4	30	5000	3.7
LPHD7446143	143	46	7.4	20	5000	3.7
LPHD7446143	143	46	7.4	20	4400	3.7
LPHD744985	85	49	7.4	1	3300	3.7
LPHD745582	82	55	7.4	20	3200	3.7
LPHD746586	86	65	7.4	25	3700	3.7
LPHD7470175	175	70	7.4	10	10000	3.7
LPHD751935	35	19	7.5	15	380	3.7
LPHD751955	55	19	7.5	20	600	3.7
LPHD753048	48	30	7.5	35	800	3.7
LPHD753048	48	30	7.5	5	1100	3.7
LPHD753060	60	30	7.5	10	1300	3.7
LPHD753085	85	30	7.5	15	1750	3.7
LPHD753085	85	30	7.5	5	2000	3.7
LPHD753142	42	31	7.5	20	500	3.7
LPHD753450	50	34	7.5	1	1350	3.7
LPHD753476	76	34	7.5	20	1600	3.7
LPHD753562	62	35	7.5	15	1450	3.7
LPHD753562	62	35	7.5	20	1300	3.7
LPHD753562	62	35	7.5	15	1550	3.7
LPHD7536128	128	36	7.5	20	3000	3.7
LPHD7538110	110	38	7.5	20	2700	3.7
LPHD7542126	126	42	7.5	8	4500	3.7
LPHD7542126	126	42	7.5	20	3100	3.7
LPHD7542126	126	42	7.5	30	3300	3.7
LPHD7542126	126	42	7.5	5	4800	3.7
LPHD7543128	128	43	7.5	20	3800	3.7
LPHD754380	80	43	7.5	5	3400	3.7
LPHD7544100	100	44	7.5	1	3350	3.7
LPHD7545135	135	45	7.5	5	5000	3.7
LPHD7545135	135	45	7.5	20	4000	3.7
LPHD7545150	150	45	7.5	20	4700	3.7
LPHD7545150	150	45	7.5	30	4580	3.7
LPHD755180	80	51	7.5	5	2500	3.7
LPHD755180	80	51	7.5	5	3500	3.7
LPHD755490	90	54	7.5	25	3100	3.7
LPHD7558150	150	58	7.5	5	7650	3.7
LPHD7564159	159	64	7.5	20	7500	3.7
LPHD7565135	135	65	7.5	1	5000	3.7
LPHD7570135	135	70	7.5	1	7700	3.7
LPHD757068	68	70	7.5	1	2800	3.7
LPHD7585186	186	85	7.5	15	12500	3.7
LPHD762035	35	20	7.6	10	400	3.7
LPHD7630100	100	30	7.6	5	2500	3.7
LPHD763048	48	30	7.6	1	1100	3.7
LPHD763048	48	30	7.6	25	800	3.7
LPHD763048	48	30	7.6	35	800	3.7
LPHD763048	48	30	7.6	20	850	3.7
LPHD763048	48	30	7.6	20	800	3.7
LPHD763048	48	30	7.6	30	800	3.7
LPHD763048	48	30	7.6	40	800	3.7
LPHD763048	48	30	7.6	30	850	3.7
LPHD7634106	106	34	7.6	30	2200	3.7
LPHD7634106	106	34	7.6	20	2400	3.7
LPHD763482	82	34	7.6	30	1800	3.7
LPHD763496	96	34	7.6	20	2100	3.7
LPHD763562	62	35	7.6	20	1100	3.7
LPHD763562	62	35	7.6	35	1300	3.7
LPHD7642126	126	42	7.6	20	3600	3.7
LPHD7642126	126	42	7.6	20	3700	3.7
LPHD7642126	126	42	7.6	30	4000	3.7
LPHD7642126	126	42	7.6	15	4500	3.7
LPHD7642126	126	42	7.6	20	3100	3.7
LPHD7643128	128	43	7.6	20	3600	3.7
LPHD764380	80	43	7.6	5	3150	3.7
LPHD7645135	135	45	7.6	25	4000	3.7
LPHD7645150	150	45	7.6	30	5000	3.7
LPHD7646143	143	46	7.6	30	5000	3.7
LPHD7649135	135	49	7.6	20	5100	3.7
LPHD7658150	150	58	7.6	15	7000	3.7
LPHD7659156	156	59	7.6	1	6000	3.7
LPHD7660119	119	60	7.6	5	6800	3.7
LPHD7664155	155	64	7.6	15	8000	3.7
LPHD7665132	132	65	7.6	1	6000	3.7
LPHD766689	89	66	7.6	5	5600	3.7
LPHD7670135	135	70	7.6	5	8100	3.7
LPHD7670175	175	70	7.6	10	10000	3.7
LPHD7672196	196	72	7.6	5	12500	3.7
LPHD7675106	106	75	7.6	1	7800	3.7
LPHD7685186	186	85	7.6	15	12500	3.7
LPHD773048	48	30	7.7	35	800	3.7
LPHD773048	48	30	7.7	1	1250	3.7
LPHD773294	94	32	7.7	20	2300	3.7
LPHD7734100	100	34	7.7	15	2500	3.7
LPHD773482	82	34	7.7	30	1800	3.7
LPHD773562	62	35	7.7	35	1300	3.7
LPHD773562	62	35	7.7	30	1300	3.7
LPHD7742126	126	42	7.7	30	4000	3.7
LPHD7743135	135	43	7.7	20	4000	3.7
LPHD7744175	175	44	7.7	1	7500	3.7
LPHD7744175	175	44	7.7	15	5900	3.7
LPHD7744175	175	44	7.7	20	5600	3.7
LPHD774590	90	45	7.7	5	3600	3.7
LPHD7746143	143	46	7.7	20	5200	3.7
LPHD7748150	150	48	7.7	15	6000	3.7
LPHD775180	80	51	7.7	1	3000	3.7
LPHD7770170	170	70	7.7	10	10000	3.7
LPHD7770175	175	70	7.7	10	10000	3.7
LPHD7785186	186	85	7.7	15	12500	3.7
LPHD782030	30	20	7.8	15	350	3.7
LPHD783048	48	30	7.8	5	1100	3.7
LPHD783048	48	30	7.8	10	1000	3.7
LPHD783082	82	30	7.8	5	2250	3.7
LPHD783082	82	30	7.8	20	1550	3.7
LPHD783082	82	30	7.8	20	1650	3.7
LPHD783085	85	30	7.8	25	1600	3.7
LPHD783476	76	34	7.8	15	2000	3.7
LPHD783496	96	34	7.8	20	1800	3.7
LPHD783496	96	34	7.8	20	2100	3.7
LPHD783496	96	34	7.8	15	2400	3.7
LPHD783496	96	34	7.8	20	2200	3.7
LPHD783496	96	34	7.8	25	2400	3.7
LPHD783542	42	35	7.8	10	1000	3.7
LPHD783562	62	35	7.8	25	1300	3.7
LPHD783562	62	35	7.8	20	1400	3.7
LPHD783562	62	35	7.8	30	1500	3.7
LPHD783562	62	35	7.8	30	1300	3.7
LPHD783562	62	35	7.8	35	1450	3.7
LPHD784078	78	40	7.8	8	2700	3.7
LPHD7842126	126	42	7.8	20	3700	3.7
LPHD784280	80	42	7.8	5	3150	3.7
LPHD7843128	128	43	7.8	1	4400	3.7
LPHD7843128	128	43	7.8	25	3600	3.7
LPHD784380	80	43	7.8	8	2900	3.7
LPHD784380	80	43	7.8	5	3100	3.7
LPHD784380	80	43	7.8	20	2300	3.7
LPHD784380	80	43	7.8	20	2550	3.7
LPHD7845119	119	45	7.8	8	4900	3.7
LPHD7845135	135	45	7.8	30	4400	3.7
LPHD7845180	180	45	7.8	20	5500	3.7
LPHD7846143	143	46	7.8	25	4600	3.7
LPHD7849135	135	49	7.8	40	4000	3.7
LPHD7849135	135	49	7.8	30	4400	3.7
LPHD7858150	150	58	7.8	15	7000	3.7
LPHD785998	98	59	7.8	25	3300	3.7
LPHD7864155	155	64	7.8	15	8000	3.7
LPHD7870170	170	70	7.8	10	10000	3.7
LPHD7870170	170	70	7.8	1	9500	3.7
LPHD7870192	192	70	7.8	1	10000	3.7
LPHD787068	68	70	7.8	1	3000	3.7
LPHD7885186	186	85	7.8	15	12500	3.7
LPHD7898225	225	98	7.8	5	21000	3.7
LPHD7898225	225	98	7.8	5	22000	3.7
LPHD7934122	122	34	7.9	20	3000	3.7
LPHD793476	76	34	7.9	15	1950	3.7
LPHD793496	96	34	7.9	25	2100	3.7
LPHD793496	96	34	7.9	20	2200	3.7
LPHD793562	62	35	7.9	40	1300	3.7
LPHD7942126	126	42	7.9	20	3800	3.7
LPHD7943128	128	43	7.9	15	4200	3.7
LPHD7943128	128	43	7.9	35	3500	3.7
LPHD7944175	175	44	7.9	20	5600	3.7
LPHD7945119	119	45	7.9	8	4900	3.7
LPHD7945150	150	45	7.9	20	5000	3.7



Hohe Energiedichte C rating Lithium-Polymer-Akku
Thickness 8.0mm to 8.9mm, 350mAh to 21000mAh, 1C to 35C

Part Number	Length (mm)	Height (mm)	Thickness (mm)	C-rating	Capacity (mAh)	Voltage (V)
LPHD802030	30	20	8.0	15	350	3.7
LPHD802437	37	24	8.0	15	600	3.7
LPHD803060	60	30	8.0	10	1300	3.7
LPHD803060	60	30	8.0	30	1200	3.7
LPHD803082	82	30	8.0	20	1650	3.7
LPHD803082	82	30	8.0	30	1800	3.7
LPHD803082	82	30	8.0	30	1500	3.7
LPHD803082	82	30	8.0	1	2300	3.7
LPHD803085	85	30	8.0	5	2400	3.7
LPHD8034122	122	34	8.0	20	2500	3.7
LPHD803496	96	34	8.0	20	2300	3.7
LPHD803562	62	35	8.0	20	1500	3.7
LPHD8036128	128	36	8.0	20	2500	3.7
LPHD804078	78	40	8.0	8	2700	3.7
LPHD8041117	117	41	8.0	5	4500	3.7
LPHD804172	72	41	8.0	1	2050	3.7
LPHD8042126	126	42	8.0	25	4200	3.7
LPHD8042126	126	42	8.0	15	4200	3.7
LPHD8042126	126	42	8.0	20	3850	3.7
LPHD804240	40	42	8.0	8	1300	3.7
LPHD8043128	128	43	8.0	35	3500	3.7
LPHD8043128	128	43	8.0	20	4000	3.7
LPHD804380	80	43	8.0	20	1900	3.7
LPHD8044175	175	44	8.0	20	5900	3.7
LPHD8045119	119	45	8.0	8	5100	3.7
LPHD8045119	119	45	8.0	5	5200	3.7
LPHD8045135	135	45	8.0	20	4400	3.7
LPHD8045150	150	45	8.0	25	5500	3.7
LPHD8045180	180	45	8.0	25	5500	3.7
LPHD804575	75	45	8.0	20	1900	3.7
LPHD805686	86	56	8.0	5	4500	3.7
LPHD8064155	155	64	8.0	1	10000	3.7
LPHD8065132	132	65	8.0	1	6500	3.7
LPHD8067100	100	67	8.0	20	4100	3.7
LPHD8067220	220	67	8.0	1	10000	3.7
LPHD8070135	135	70	8.0	1	10000	3.7
LPHD8070170	170	70	8.0	1	8000	3.7
LPHD8070170	170	70	8.0	5	12600	3.7
LPHD8070170	170	70	8.0	10	10000	3.7
LPHD8070170	170	70	8.0	1	12600	3.7
LPHD8072196	196	72	8.0	1	10000	3.7
LPHD8083145	145	83	8.0	8	10500	3.7
LPHD8098225	225	98	8.0	5	21000	3.7
LPHD812530	30	25	8.1	15	450	3.7
LPHD8134122	122	34	8.1	20	2500	3.7
LPHD813496	96	34	8.1	20	2300	3.7
LPHD8142126	126	42	8.1	20	4000	3.7
LPHD8144107	107	44	8.1	5	4800	3.7
LPHD8145119	119	45	8.1	5	5200	3.7
LPHD8148150	150	48	8.1	15	6000	3.7
LPHD8164155	155	64	8.1	20	8000	3.7
LPHD8164159	159	64	8.1	20	8000	3.7
LPHD821840	40	18	8.2	1	450	3.7
LPHD821996	96	19	8.2	15	1350	3.7
LPHD822530	30	25	8.2	15	450	3.7
LPHD822595	95	25	8.2	1	1500	3.7
LPHD822595	95	25	8.2	5	2100	3.7
LPHD823082	82	30	8.2	15	1800	3.7
LPHD823082	82	30	8.2	20	1800	3.7
LPHD823362	62	33	8.2	5	1800	3.7
LPHD8234100	100	34	8.2	20	2500	3.7
LPHD8234106	106	34	8.2	20	2600	3.7
LPHD8234122	122	34	8.2	20	2600	3.7
LPHD823496	96	34	8.2	20	2400	3.7
LPHD823496	96	34	8.2	10	2100	3.7
LPHD823496	96	34	8.2	30	2300	3.7
LPHD823496	96	34	8.2	25	2200	3.7
LPHD823562	62	35	8.2	25	1600	3.7
LPHD823990	90	39	8.2	1	3700	3.7
LPHD8242126	126	42	8.2	5	5300	3.7
LPHD8242126	126	42	8.2	20	4000	3.7
LPHD8242126	126	42	8.2	30	4300	3.7
LPHD8242126	126	42	8.2	30	3800	3.7
LPHD8242126	126	42	8.2	20	4500	3.7
LPHD824240	40	42	8.2	10	1300	3.7
LPHD8243128	128	43	8.2	20	4000	3.7
LPHD824380	80	43	8.2	5	3400	3.7
LPHD824396	96	43	8.2	5	3900	3.7
LPHD8244175	175	44	8.2	20	5900	3.7
LPHD8245135	135	45	8.2	30	4400	3.7
LPHD8245135	135	45	8.2	20	5100	3.7
LPHD8245135	135	45	8.2	25	4400	3.7
LPHD8245150	150	45	8.2	20	5000	3.7
LPHD8245150	150	45	8.2	20	5500	3.7
LPHD8245150	150	45	8.2	20	5300	3.7
LPHD8248150	150	48	8.2	15	6000	3.7
LPHD8249135	135	49	8.2	8	5800	3.7
LPHD824992	92	49	8.2	25	2500	3.7
LPHD8255270	270	55	8.2	1	17300	3.7
LPHD8264155	155	64	8.2	20	8000	3.7
LPHD8265135	135	65	8.2	1	9100	3.7
LPHD8270170	170	70	8.2	1	10000	3.7
LPHD8272196	196	72	8.2	1	12500	3.7
LPHD8285155	155	85	8.2	10	12000	3.7
LPHD8298125	125	98	8.2	15	10500	3.7
LPHD833048	48	30	8.3	15	1000	3.7
LPHD8334122	122	34	8.3	10	3500	3.7
LPHD833496	96	34	8.3	35	2200	3.7
LPHD833496	96	34	8.3	30	2200	3.7
LPHD833496	96	34	8.3	5	3200	3.7
LPHD834240	40	42	8.3	10	1300	3.7
LPHD8343128	128	43	8.3	1	5000	3.7
LPHD8345150	150	45	8.3	25	5000	3.7
LPHD8345150	150	45	8.3	20	5100	3.7
LPHD8345150	150	45	8.3	30	5200	3.7
LPHD8346143	143	46	8.3	20	5000	3.7
LPHD8355270	270	55	8.3	5	15000	3.7
LPHD835686	86	56	8.3	1	5200	3.7
LPHD8358150	150	58	8.3	15	7500	3.7
LPHD8363124	124	63	8.3	15	7500	3.7
LPHD8363135	135	63	8.3	15	7000	3.7
LPHD8364155	155	64	8.3	20	8000	3.7
LPHD8365132	132	65	8.3	1	8000	3.7
LPHD8365132	132	65	8.3	1	8500	3.7
LPHD8365135	135	65	8.3	1	8500	3.7
LPHD8370175	175	70	8.3	10	12000	3.7
LPHD842978	78	29	8.4	30	1500	3.7
LPHD843082	82	30	8.4	20	1800	3.7
LPHD843085	85	30	8.4	5	2400	3.7
LPHD8432115	115	32	8.4	10	3300	3.7
LPHD8434106	106	34	8.4	20	2700	3.7
LPHD843496	96	34	8.4	35	2200	3.7
LPHD843562	62	35	8.4	30	1600	3.7
LPHD843562	62	35	8.4	20	1600	3.7
LPHD844295	95	42	8.4	1	4200	3.7
LPHD8443128	128	43	8.4	20	4200	3.7
LPHD8443128	128	43	8.4	8	5050	3.7
LPHD8445150	150	45	8.4	25	5000	3.7
LPHD8463124	124	63	8.4	15	7500	3.7
LPHD8464204	204	64	8.4	5	13800	3.7
LPHD8465132	132	65	8.4	1	6000	3.7
LPHD846586	86	65	8.4	1	6000	3.7
LPHD8467105	105	67	8.4	25	4000	3.7
LPHD8467220	220	67	8.4	1	16000	3.7
LPHD8498220	220	98	8.4	5	21000	3.7
LPHD852845	45	28	8.5	1	1100	3.7
LPHD8534106	106	34	8.5	20	2600	3.7
LPHD8534113	113	34	8.5	5	4100	3.7
LPHD853450	50	34	8.5	1	1500	3.7
LPHD853496	96	34	8.5	15	2700	3.7
LPHD853496	96	34	8.5	20	2400	3.7
LPHD853496	96	34	8.5	20	2700	3.7
LPHD853562	62	35	8.5	30	1600	3.7
LPHD8536128	128	36	8.5	20	3800	3.7
LPHD853861	61	38	8.5	1	2500	3.7
LPHD854066	66	40	8.5	30	1850	3.7
LPHD8542121	121	42	8.5	20	3300	3.7
LPHD8542126	126	42	8.5	25	4200	3.7
LPHD8542126	126	42	8.5	15	4500	3.7
LPHD8542126	126	42	8.5	20	4150	3.7
LPHD8542126	126	42	8.5	15	5200	3.7
LPHD8542126	126	42	8.5	20	4600	3.7
LPHD8543128	128	43	8.5	35	3700	3.7
LPHD8545135	135	45	8.5	25	4000	3.7
LPHD8545135	135	45	8.5	25	4500	3.7
LPHD8545150	150	45	8.5	20	5300	3.7
LPHD8546143	143	46	8.5	20	5100	3.7
LPHD8548150	150	48	8.5	20	6000	3.7
LPHD855686	86	56	8.5	1	5500	3.7
LPHD8559156	156	59	8.5	1	10000	3.7
LPHD8563124	124	63	8.5	15	7500	3.7
LPHD8564155	155	64	8.5	1	10000	3.7
LPHD8564159	159	64	8.5	5	10000	3.7
LPHD856689	89	66	8.5	5	6300	3.7
LPHD8578156	156	78	8.5	25	8000	3.7
LPHD8585187	187	85	8.5	10	15000	3.7
LPHD8588106	106	88	8.5	5	10000	3.7
LPHD863048	48	30	8.6	30	1000	3.7
LPHD863060	60	30	8.6	30	1200	3.7
LPHD8634122	122	34	8.6	20	2600	3.7
LPHD863496	96	34	8.6	5	3400	3.7
LPHD863562	62	35	8.6	30	1550	3.7
LPHD8636128	128	36	8.6	20	3500	3.7
LPHD8642124	124	42	8.6	20	4400	3.7
LPHD8642126	126	42	8.6	15	5000	3.7
LPHD8642126	126	42	8.6	30	4500	3.7
LPHD864270	70	42	8.6	15	2500	3.7
LPHD8643128	128	43	8.6	20	4300	3.7
LPHD8643128	128	43	8.6	35	4000	3.7
LPHD8645150	150	45	8.6	30	5000	3.7
LPHD8645150	150	45	8.6	35	5000	3.7
LPHD864985	85	49	8.6	5	4400	3.7
LPHD865998	98	59	8.6	5	5700	3.7
LPHD8663124	124	63	8.6	15	7500	3.7
LPHD873085	85	30	8.7	1	2600	3.7
LPHD873562	62	35	8.7	30	1550	3.7
LPHD8736128	128	36	8.7	20	3600	3.7
LPHD8742126	126	42	8.7	35	4000	3.7
LPHD8743128	128	43	8.7	35	4000	3.7
LPHD8745135	135	45	8.7	20	5100	3.7
LPHD8745150	150	45	8.7	35	5000	3.7
LPHD874985	85	49	8.7	5	4400	3.7
LPHD875686	86	56	8.7	20	4000	3.7
LPHD875998	98	59	8.7	10	5600	3.7
LPHD8763124	124	63	8.7	15	7500	3.7
LPHD8767100	100	67	8.7	1	5000	3.7
LPHD8770175	175	70	8.7	5	13800	3.7
LPHD8780145	145	80	8.7	8	11000	3.7
LPHD8785183	183	85	8.7	10	15000	3.7
LPHD882448	48	24	8.8	30	850	3.7
LPHD882892	92	28	8.8	10	2450	3.7
LPHD882978	78	29	8.8	1	2100	3.7
LPHD8830105	105	30	8.8	5	3250	3.7
LPHD883048	48	30	8.8	15	1100	3.7
LPHD883082	82	30	8.8	20	1800	3.7
LPHD8834122	122	34	8.8	20	3400	3.7
LPHD8834122	122	34	8.8	10	4000	3.7
LPHD883465	65	34	8.8	1	2250	3.7
LPHD883476	76	34	8.8	20	2200	3.7
LPHD8842126	126	42	8.8	20	4400	3.7
LPHD8842126	126	42	8.8	35	4000	3.7
LPHD8843128	128	43	8.8	20	4250	3.7
LPHD8843128	128	43	8.8	30	4000	3.7
LPHD8845150	150	45	8.8	30	5600	3.7
LPHD884765	65	47	8.8	1	3000	3.7
LPHD884940	40	49	8.8	30	1300	3.7
LPHD884996	96	49	8.8	5	4900	3.7
LPHD8850140	140	50	8.8	10	7150	3.7
LPHD885097	97	50	8.8	5	4900	3.7
LPHD885998	98	59	8.8	10	5300	3.7
LPHD8864159	159	64	8.8	15	10000	3.7
LPHD8865132	132	65	8.8	1	6000	3.7
LPHD8867222	222	67	8.8	5	17000	3.7
LPHD886868	68	68	8.8	1	4800	3.7
LPHD8870170	170	70	8.8	1	10000	3.7
LPHD8870175	175	70	8.8	10	12000	3.7
LPHD887768	68	77	8.8	8	4700	3.7
LPHD892442	42	24	8.9	15	800	3.7
LPHD892448	48	24	8.9	30	850	3.7
LPHD893048	48	30	8.9	15	1100	3.7
LPHD8931105	105	31	8.9	5	3400	3.7
LPHD8934106	106	34	8.9	35	2650	3.7
LPHD8934106	106	34	8.9	30	3000	3.7
LPHD893496	96	34	8.9	25	2400	3.7
LPHD8936128	128	36	8.9	15	4200	3.7
LPHD8943158	158	43	8.9	5	7600	3.7
LPHD8945150	150	45	8.9	25	5300	3.7
LPHD8945150	150	45	8.9	20	5500	3.7
LPHD895592	92	55	8.9	5	5200	3.7
LPHD896077	77	60	8.9	1	5000	3.7
LPHD8967217	217	67	8.9	15	13900	3.7
LPHD8967220	220	67	8.9	15	14000	3.7



Hohe Energiedichte C rating Lithium-Polymer-Akku
Thickness 9.0mm to 9.9mm, 1000mAh to 2100mAh, 1C to 40C

Part Number	Length (mm)	Height (mm)	Thickness (mm)	C-rating	Capacity (mAh)	Voltage (V)
LPHD9034106	106	34	9.0	35	2650	3.7
LPHD903562	62	35	9.0	20	1550	3.7
LPHD903562	62	35	9.0	35	1550	3.7
LPHD9036128	128	36	9.0	20	3800	3.7
LPHD904172	72	41	9.0	1	2300	3.7
LPHD9042124	124	42	9.0	1	6000	3.7
LPHD9042126	126	42	9.0	20	4500	3.7
LPHD9042126	126	42	9.0	20	3800	3.7
LPHD9043128	128	43	9.0	20	4400	3.7
LPHD9043158	158	43	9.0	5	7600	3.7
LPHD904360	60	43	9.0	20	2100	3.7
LPHD9045150	150	45	9.0	30	5000	3.7
LPHD9045150	150	45	9.0	30	5200	3.7
LPHD9045180	180	45	9.0	20	7050	3.7
LPHD905290	90	52	9.0	1	3900	3.7
LPHD905686	86	56	9.0	20	4000	3.7
LPHD9059156	156	59	9.0	1	10000	3.7
LPHD9059156	156	59	9.0	30	8000	3.7
LPHD906077	77	60	9.0	1	5000	3.7
LPHD9070170	170	70	9.0	1	10000	3.7
LPHD9070175	175	70	9.0	5	12500	3.7
LPHD913096	96	30	9.1	5	3150	3.7
LPHD9145180	180	45	9.1	20	7050	3.7
LPHD9159156	156	59	9.1	5	10000	3.7
LPHD9170175	175	70	9.1	10	12000	3.7
LPHD923048	48	30	9.2	30	1000	3.7
LPHD923085	85	30	9.2	1	2000	3.7
LPHD9234122	122	34	9.2	20	3350	3.7
LPHD923496	96	34	9.2	20	2100	3.7
LPHD9236128	128	36	9.2	15	4750	3.7
LPHD9242125	125	42	9.2	40	4000	3.7
LPHD9242126	126	42	9.2	25	4200	3.7
LPHD9242126	126	42	9.2	20	4600	3.7
LPHD924358	58	43	9.2	20	2000	3.7
LPHD9245150	150	45	9.2	30	6000	3.7
LPHD9245150	150	45	9.2	30	5550	3.7
LPHD9245180	180	45	9.2	20	7050	3.7
LPHD924590	90	45	9.2	1	5000	3.7
LPHD9246143	143	46	9.2	30	6000	3.7
LPHD9259156	156	59	9.2	30	8000	3.7
LPHD9267100	100	67	9.2	1	5000	3.7
LPHD9270170	170	70	9.2	5	12500	3.7
LPHD9270175	175	70	9.2	10	12000	3.7
LPHD927560	60	75	9.2	1	4700	3.7
LPHD9276119	119	76	9.2	20	6400	3.7
LPHD9282262	262	82	9.2	8	24000	3.7
LPHD933048	48	30	9.3	15	1100	3.7
LPHD933496	96	34	9.3	20	2700	3.7
LPHD9342126	126	42	9.3	20	4600	3.7
LPHD9342126	126	42	9.3	10	5000	3.7
LPHD9343128	128	43	9.3	20	4800	3.7
LPHD9345123	123	45	9.3	8	6300	3.7
LPHD9345135	135	45	9.3	15	6100	3.7
LPHD9345150	150	45	9.3	25	5800	3.7
LPHD9345150	150	45	9.3	35	5800	3.7
LPHD935265	65	52	9.3	1	3950	3.7
LPHD9355175	175	55	9.3	1	8000	3.7
LPHD937768	68	77	9.3	8	4900	3.7
LPHD937780	80	77	9.3	8	6000	3.7
LPHD942072	72	20	9.4	1	1550	3.7
LPHD9436128	128	36	9.4	20	4000	3.7
LPHD9438110	110	38	9.4	20	3800	3.7
LPHD9442126	126	42	9.4	20	4800	3.7
LPHD9442126	126	42	9.4	20	5200	3.7
LPHD9445135	135	45	9.4	15	6100	3.7
LPHD944590	90	45	9.4	20	3600	3.7
LPHD9449135	135	49	9.4	25	5800	3.7
LPHD945170	70	51	9.4	1	4000	3.7
LPHD945686	86	56	9.4	1	6000	3.7
LPHD9459134	134	59	9.4	1	10000	3.7
LPHD9467100	100	67	9.4	1	7800	3.7
LPHD9470175	175	70	9.4	10	12000	3.7
LPHD9477123	123	77	9.4	20	6400	3.7
LPHD952595	95	25	9.5	20	1500	3.7
LPHD953048	48	30	9.5	15	1100	3.7
LPHD953496	96	34	9.5	25	2600	3.7
LPHD9536128	128	36	9.5	8	5000	3.7
LPHD9536128	128	36	9.5	20	4000	3.7
LPHD9544100	100	44	9.5	20	4000	3.7
LPHD9545123	123	45	9.5	8	6300	3.7
LPHD9545135	135	45	9.5	15	5800	3.7
LPHD9556117	117	56	9.5	15	6300	3.7
LPHD955686	86	56	9.5	20	4500	3.7
LPHD9564159	159	64	9.5	15	10000	3.7
LPHD9567220	220	67	9.5	1	17500	3.7
LPHD9570170	170	70	9.5	5	15000	3.7
LPHD9570170	170	70	9.5	10	12000	3.7
LPHD9590190	190	90	9.5	5	21000	3.7
LPHD963476	76	34	9.6	1	3000	3.7
LPHD963476	76	34	9.6	20	2200	3.7
LPHD9642126	126	42	9.6	35	4700	3.7
LPHD9642126	126	42	9.6	30	5000	3.7
LPHD9643128	128	43	9.6	20	5200	3.7
LPHD9645135	135	45	9.6	20	5750	3.7
LPHD9645135	135	45	9.6	15	5800	3.7
LPHD964590	90	45	9.6	20	3500	3.7
LPHD9646143	143	46	9.6	5	8000	3.7
LPHD9659156	156	59	9.6	30	8000	3.7
LPHD9659156	156	59	9.6	5	10000	3.7
LPHD9664155	155	64	9.6	15	10000	3.7
LPHD9670135	135	70	9.6	5	10000	3.7
LPHD9670170	170	70	9.6	1	10000	3.7
LPHD9675175	175	75	9.6	5	15000	3.7
LPHD9742126	126	42	9.7	20	4800	3.7
LPHD9742126	126	42	9.7	20	5000	3.7
LPHD9742126	126	42	9.7	30	5000	3.7
LPHD9742126	126	42	9.7	10	5900	3.7
LPHD9743128	128	43	9.7	35	4300	3.7
LPHD974356	56	43	9.7	20	2100	3.7
LPHD974360	60	43	9.7	20	2100	3.7
LPHD974590	90	45	9.7	5	5000	3.7
LPHD975265	65	52	9.7	5	4000	3.7
LPHD9759156	156	59	9.7	5	10000	3.7
LPHD9759156	156	59	9.7	30	8000	3.7
LPHD9764155	155	64	9.7	15	10000	3.7
LPHD9764159	159	64	9.7	15	10000	3.7
LPHD9770170	170	70	9.7	1	15000	3.7
LPHD982741	41	27	9.8	1	950	3.7
LPHD983758	58	37	9.8	1	2500	3.7
LPHD984050	50	40	9.8	1	2000	3.7
LPHD9842126	126	42	9.8	35	5200	3.7
LPHD9843128	128	43	9.8	20	4800	3.7
LPHD9845119	119	45	9.8	8	6300	3.7
LPHD9845135	135	45	9.8	8	7000	3.7
LPHD9846125	125	46	9.8	5	6950	3.7
LPHD9859156	156	59	9.8	30	8000	3.7
LPHD9859156	156	59	9.8	5	10000	3.7
LPHD9863139	139	63	9.8	5	10000	3.7
LPHD9864155	155	64	9.8	15	10000	3.7
LPHD9864159	159	64	9.8	15	10000	3.7
LPHD986870	70	68	9.8	1	6000	3.7
LPHD9870170	170	70	9.8	1	10000	3.7
LPHD9870170	170	70	9.8	10	12000	3.7
LPHD987776	76	77	9.8	1	7200	3.7
LPHD9890190	190	90	9.8	8	21000	3.7
LPHD989092	92	90	9.8	15	8000	3.7
LPHD9942126	126	42	9.9	20	5000	3.7
LPHD9945135	135	45	9.9	8	7000	3.7
LPHD998273	73	82	9.9	15	6100	3.7



Hohe Energiedichte C rating Lithium-Polymer-Akku
Thickness 10mm to 19mm, 1700mAh to 29500mAh, 1C to 40C

Part Number	Length (mm)	Height (mm)	Thickness (mm)	C-rating	Capacity (mAh)	Voltage (V)
LPHD103450	50	34	10.0	1	1800	3.7
LPHD103450	50	34	10.0	8	1700	3.7
LPHD103476	76	34	10.0	15	2400	3.7
LPHD103992	92	39	10.0	20	3250	3.7
LPHD1042126	126	42	10.0	20	5000	3.7
LPHD1045135	135	45	10.0	15	6100	3.7
LPHD1045135	135	45	10.0	8	7000	3.7
LPHD1045150	150	45	10.0	35	5800	3.7
LPHD104694	94	46	10.0	1	4600	3.7
LPHD1047115	115	47	10.0	8	6300	3.7
LPHD1048150	150	48	10.0	5	8500	3.7
LPHD104992	92	49	10.0	1	6000	3.7
LPHD112448	48	24	11.0	20	1000	3.7
LPHD1142126	126	42	11.0	25	5500	3.7
LPHD1142126	126	42	11.0	15	5600	3.7
LPHD1145135	135	45	11.0	8	7000	3.7
LPHD1164159	159	64	11.0	5	12500	3.7
LPHD119092	92	90	11.0	15	8000	3.7
LPHD123864	64	38	12.0	1	2700	3.7
LPHD1242126	126	42	12.0	20	5200	3.7
LPHD1242126	126	42	12.0	20	5450	3.7
LPHD1242126	126	42	12.0	35	4700	3.7
LPHD1245135	135	45	12.0	15	6100	3.7
LPHD1270175	175	70	12.0	5	15000	3.7
LPHD1342124	124	42	13.0	10	6000	3.7
LPHD1342126	126	42	13.0	25	5100	3.7
LPHD1342126	126	42	13.0	15	6100	3.7
LPHD1342126	126	42	13.0	10	6300	3.7
LPHD1342126	126	42	13.0	30	5300	3.7
LPHD1342126	126	42	13.0	20	5200	3.7
LPHD1342126	126	42	13.0	30	5000	3.7
LPHD1345150	150	45	13.0	20	6900	3.7
LPHD1347115	115	47	13.0	8	6850	3.7
LPHD1347115	115	47	13.0	8	6300	3.7
LPHD1355270	270	55	13.0	1	21000	3.7
LPHD1355270	270	55	13.0	5	21000	3.7
LPHD1363139	139	63	13.0	5	11300	3.7
LPHD1370170	170	70	13.0	1	16000	3.7
LPHD1375175	175	75	13.0	15	15000	3.7
LPHD1390190	190	90	13.0	5	21500	3.7
LPHD1442124	124	42	14.0	20	5500	3.7
LPHD1442124	124	42	14.0	35	5000	3.7
LPHD1442126	126	42	14.0	30	5000	3.7
LPHD144590	90	45	14.0	5	5000	3.7
LPHD1447115	115	47	14.0	8	6300	3.7
LPHD1475175	175	75	14.0	15	15000	3.7
LPHD153288	88	32	15.0	8	3400	3.7
LPHD153288	88	32	15.0	5	3400	3.7
LPHD1542124	124	42	15.0	20	5500	3.7
LPHD1542124	124	42	15.0	30	5000	3.7
LPHD1542126	126	42	15.0	30	5000	3.7
LPHD1542126	126	42	15.0	40	4700	3.7
LPHD1542126	126	42	15.0	20	5200	3.7
LPHD1542126	126	42	15.0	10	6000	3.7
LPHD1542126	126	42	15.0	15	6600	3.7
LPHD1543128	128	43	15.0	25	5100	3.7
LPHD1543128	128	43	15.0	15	5600	3.7
LPHD1543128	128	43	15.0	10	6200	3.7
LPHD1570145	145	70	15.0	5	12500	3.7
LPHD1575175	175	75	15.0	10	15000	3.7
LPHD1575175	175	75	15.0	15	15000	3.7
LPHD1590190	190	90	15.0	8	21000	3.7
LPHD162072	72	20	16.0	5	1800	3.7
LPHD1630200	200	30	16.0	5	32200	3.7
LPHD1642126	126	42	16.0	15	6600	3.7
LPHD1642124	124	42	16.0	20	5500	3.7
LPHD1643126	126	43	16.0	15	6350	3.7
LPHD1645150	150	45	16.0	20	6900	3.7
LPHD166479	79	64	16.0	15	5700	3.7
LPHD1675175	175	75	16.0	10	15000	3.7
LPHD1722185	185	22	17.0	8	25500	3.7
LPHD1730185	185	30	17.0	8	27500	3.7
LPHD1730200	200	30	17.0	8	29500	3.7
LPHD1742126	126	42	17.0	20	5700	3.7
LPHD1742126	126	42	17.0	8	7000	3.7
LPHD1742126	126	42	17.0	15	6600	3.7
LPHD1743126	126	43	17.0	15	6350	3.7
LPHD1743128	128	43	17.0	20	5600	3.7
LPHD1745150	150	45	17.0	20	6900	3.7
LPHD1775175	175	75	17.0	10	15000	3.7
LPHD1799185	185	99	17.0	8	29500	3.7
LPHD1790185	185	90	17.0	8	21000	3.7
LPHD1790190	190	90	17.0	8	21000	3.7
LPHD1790190	190	90	17.0	8	22500	3.7
LPHD1790190	190	90	17.0	5	24500	3.7
LPHD1790215	215	90	17.0	8	24000	3.7
LPHD184180	80	41	18.0	15	4200	3.7
LPHD1842124	124	42	18.0	20	5700	3.7
LPHD1842124	124	42	18.0	35	5200	3.7
LPHD1842126	126	42	18.0	8	7000	3.7
LPHD1842126	126	42	18.0	35	5200	3.7
LPHD1842126	126	42	18.0	15	6600	3.7
LPHD1842126	126	42	18.0	10	6550	3.7
LPHD1843126	126	43	18.0	5	7250	3.7
LPHD1842126	126	42	18.0	15	6300	3.7
LPHD1875170	170	75	18.0	10	15000	3.7
LPHD1875175	175	75	18.0	10	15000	3.7
LPHD1875175	175	75	18.0	10	16800	3.7
LPHD1885155	155	85	18.0	10	16800	3.7
LPHD1890190	190	90	18.0	8	21000	3.7
LPHD1940121	121	40	19.0	8	6050	3.7
LPHD1942126	126	42	19.0	8	7000	3.7
LPHD1942126	126	42	19.0	10	6550	3.7
LPHD1942126	126	42	19.0	15	6500	3.7
LPHD1942126	126	42	19.0	15	6300	3.7
LPHD1942126	126	42	19.0	35	5200	3.7
LPHD1943126	126	43	19.0	5	7250	3.7
LPHD1943126	126	43	19.0	15	6350	3.7
LPHD196479	79	64	19.0	15	5600	3.7
LPHD1985155	155	85	19.0	10	16800	3.7



Hohe Energiedichte C rating Lithium-Polymer-Akku
Thickness 20mm to 22mm, 2000mAh to 7950mAh, 5C to 30C

Part Number	Length (mm)	Height (mm)	Thickness (mm)	C-rating	Capacity (mAh)	Voltage (V)
LPHD202978	78	29	20	30	2000	3.7
LPHD204180	80	41	20	15	3900	3.7
LPHD2042126	126	42	20	8	6900	3.7
LPHD2042126	126	42	20	15	6000	3.7
LPHD2042126	126	42	20	15	6300	3.7
LPHD2042126	126	42	20	15	6600	3.7
LPHD2042126	126	42	20	10	6550	3.7
LPHD2042126	126	42	20	8	7500	3.7
LPHD2042126	126	42	20.0	8	7000	3.7
LPHD2042126	126	42	20.0	15	6950	3.7
LPHD2042126	126	42	20.0	10	7000	3.7
LPHD2043126	126	43	20	5	7950	3.7
LPHD2043127	127	43	20.0	15	7000	3.7
LPHD206479	79	64	2.0	10	5900	3.7
LPHD2142126	126	42	21.0	15	6300	3.7
LPHD2142126	126	42	21.0	10	6550	3.7
LPHD2143126	126	43	21	5	7500	3.7
LPHD2242126	126	42	22.0	20	6050	3.7
